Motor driven Flat Bed Screen Printing Machines

  • Min.Order Quantity: 1 set
  • Supply Ability: 10 per Month
  • Port: Shenzhen
  • Payment Terms: T/T, L/C, Western Union
  • Product Detail

    Product Tags

    Motor Driven Flat Bed Screen Printing Machines

    Application:

    Suitable for printing on all kinds of flat materials such as membrane switch, PCB, LCD display, ceramic decals, paper, glass, etc.

    Trafic signal sheet 1

    Trafic signal sheet 2

    Trafic signal sheet 3

    Advantages:

    Mitsubishi PLC control; Independent motor-driven systems for print carriage and screen frame up &down movement;

    Imported speed reducer and inverters ensure smooth print strike;

    High quality components: imported cylinders, Mitsubishi PLC, Schneider contactor, Omron relay, etc.

    Smooth stroke: dedicated drive systems ensure vibration-free print cycling; Universal master-frame accepts most frame types and disengages easily for fast cleanup;

    Print with any types of solvent and UV inks;

    Mature technique: 20 years’ experience of screen printing equipment production; Affordable price and production costs.



    Features:

    1.Independent AC motor drives for print carriage and head lift.

    2.Imported variable frequency drives ensure smooth, precise operation.

    3.Mitsubishi PLC control, imported speed reducer assures smooth print stroke.

    4.Printing head motion on imported precision linear guide rails.

    5.Printing stroke controlled by imported sensors, tool-free adjustment to suit various screen sizes.

    3 (1)

    6.High quality electrical components: Panasonic / Omron relay, Schneider contactor and switch, etc.

    7.Optional working mode on control panel: Manual, Semi-automatic, full automatic.

    8.Printing table equipped with 3 sets of micrometric adjustment knobs for precision alignment in different directions.

    1

    9.Variable squeegee/flood speed controls are adjusted by simply turning a dial.

    10.Equipped with auto peel-off system, peel-off angle and speed are variable adjustable, guaranteed the printing quality.

    11.Rapid screen change is enhanced by the ability of the press to rotate the squeegee/ flood-bar assembly 90° over the drip tray.

    12.Adjustable screen holders accommodate a wide variety of screen sizes.

    13.Manual clamps lock frame securely in place.

    14.Separate independent foot pedals for hands-free single cycle printing.

    15.Cycle interruption bars stop press when activated.

    16. Honey comb structure print bed. Powerful vacuum turbine delivers strong suction during printing, with a pre-vacuum for hard to register materials.

    17.4.4 cm (1.76″) thick heavy-gauge aluminum alloy print table, stick with 1.5mm stainless steel.

     4

     Specifications:

    Model LL-CP4060BX LL-CP5070BX LL-CP6090BX LL-CP8012BX LL-CP8015BX
    Max. Print Area(mm) 400*600 500*700 600*900 800*1200 800*1500
    Max. Frame Size(mm) 640*950 760*1100 980*1380 1150*1740 1200*1950
    Table Size(mm) 500*700 600*800 700*1000 900*1500 900*1700
    Max. Print Thickness(mm) 0.1-30 0.1-30 0.1-50 0.1-50 0.1-50
    Working Height(mm) 890 890 890 890 890
    Max. Cycle Speed(pcs/h) 500 500 500 500 400
    Power Source 220v,3kw,50/60hz 220v,3kw,50/60hz 380v,3kw,50/60hz 380v,4kw,50/60hz 380v,4.8kw,50/60hz
    Machine Size(L*W*H) 930*1160*1650 1030*1310*1650 1250*1690*1750 1740X1420X1650 1450*2210*1700
