Applications: Pad printer is widely applied in many industries including toys, plastic, electronic, glass, metal, electrical appliances, ceramics, die-casting products, optical, sporting goods, stationery, etc. For example, rulers, pens, golf balls, ping-pong, eyes of doll, cap of bottle, watches, cameras, ceramic, pharmaceutical and medical equipment, rackets, tapes, electronic components, IC, CPU, DRAM, keyboard, mouse, cell phone shell, decorative signs, etc.
Features:
Fully electric servo motor control, simple operation using touch screen display.
125mm-800mm working stroke can be customized, ink cup and ink basin design.
Programmable up and down, forward and rear stroke.
Heavy-duty construction with cabinet.
Stable, durable working and fine workmanship.
Foot pedal operation for single cycle.
Pad cleaning.
Complying with CE safety standards.
Specifications:
|
Model |
LP-C90-200SC |
|
Ink system |
Ink cup |
|
Plate size(mm) |
100*200mm |
|
Ink cup size(mm) |
90mm |
|
Max. print speed |
1000-1500 Pieces/hour |
|
Driven |
Electric servo motor |
|
Air pressure |
5-6 bar |
|
Control system |
PLC and Touch screen display |
|
Voltage |
110/220/230V 50/60HZ |
|
Weight(kg) |
80 |
|
Machine dimension(L*W*H mm) |
660*400*1630 |
